48

AVR2070

8240B-AVR-06/09

Routing

Start

Am I

coordinator?

Coord

Send routing

packet if

necessary

Resend packet to

first router in chain

Is dest a child

of mine?

No

Send packet to

child (destination)

Yes

Is this frame

from parent?

Router

Packet is from

child – resend to

my parent

No

Yes

Is destination

my child?

Yes

Resend packet to
child (destination)

No

Send to default router (see

macConfig.lastRoute)

End

Figure B-5 Frame routing overview
