Kaman Precision Products PART NO: 860522-001
www.kamansensors.com Last Revised 11/16/2012
- 13 -
PART 5 – GENERAL SPECIFICATIONS & TYPICAL
PERFORMANCE
Parameter Value
Units Comments
Target Material Aluminum is
preferred
Most conductive materials can be
considered
Null Gap See Data
Sheet
Range and sensor dependant.
See Data Sheet.
Range See Data
Sheet
See Data Sheet
Output Voltage +/-10 Volts Typical
Non-Linearity <0.5 %FSO Typical
Resolution at Null
(p-p at 1kHz BW)
<0.004 %FSO Typical
Resolution at FSO
(p-p @ 1kHz BW)
<0.015 %FSO Typical
TempCo at Null <0.005 %FSO/ o C Typical
TempCo at FSO <0.02 %FSO/
o
C Typical
Power Dissipation at 15N
Sensor Head
< 0.5 mW/sensor Typical
Power Dissipation at 20N
Sensor Head
< 2 mW/sensor Typical
Power Dissipation
(Electronics)
<1.35 Watts
Frequency Response 0 - 20 kHz
Input Voltage +/-15 Volts
Output Impedance <1 Ohm
Weight <8 oz Enclosure Version (Typical)
Operating Temperature
 Electronics:
+32to +140 o F (0C to +60 o C)
 Sensors:
-62 o F to +220 o F (-52 o C to +105 o C)
 Cryogenic 20N Sensor: +4 o K to +220 o F (+105 o C)
Storage Temperature Range
 Electronics:
-26
o
F to +180
o
F (-32
o
C to +82
o
C)
 Sensors:
-62
o
F to +220
o
F (-52
o
C to +105
o
C)
 Cryogenic 20N Sensor: +4 o K to +220 o F (+105 o C)
