Page 10: C-1700n p ar ts list
C-1700N
Replacement Parts Drawing
Page 10
45
42
44
43
46
47
48
49
50
48
51
52
53
54
12
17
18
20
21
22
23
26
27
29
37
36
38
39
41
40
25
24
13
10
11
15
14
16
55
9
2
1
4
3
6
8
7
28
19
30
31
32
33
5
34
35
C-1700N
Page 11
Item
Part No
Description
Qty
Item
Part No
Description
Qty
C-1700N P
AR
TS LIST
1
90002-086
Screen, FootV
alve, P
.P
.
2
2
90002-214
Body
, FootV
alve, PVDF
2
3
90003-126
O-ring Seat, FootV
alve,
V
iton
2
90003-129
O-ring Seat, FootV
alve, E.P
.
2
4
90008-062
Ball, FootV
alve, Ceramic
2
5
90003-014
O-ring, FootV
alve,
V
iton
2
90003-015
O-ring, FootV
alve, E.P
.
2
6
90002-215
Adapter
, FootV
alve, PVDF
2
7
71000-324
FootV
alve S/A, C-340E, EP
2
71000-325
FootV
alve S/A, C-340V
,
VT
2
8
90008-068
Ceramic weight, C-346
2
9
70000-638
T
ube Indicator Glass 3/8 x 5FT
2
76000-171
T
ube Suction 1/4 x 5FT
2
10
90002-077
T
ube Nut, .37T
, P
.P
.
4
90002-047
T
ube Nut, .25T
, P
.P
.
4
1
1
71000-204
Adapter S/A
Bullet .37T
V
iton
4
71000-205
Adapter S/A
Bullet .37T
EP
4
71000-224
Adapter S/A
Bullet .37T
Silicon
4
71000-225
Adapter S/A
Bullet .25T
V
iton
4
71000-226
Adapter S/A
Bullet .25T
EP
4
71000-227
Adapter S/A
Bullet .25T
Silicon
4
12
71000-195
Cartridge Bullet
V
alve S/A, Double-Ball
2
13
70004-074
Cover P/Head, HD Chem-Feed logo
2
70004-071
Cover P/Head, HD Noir logo
2
70004-086
Cover P/Head, HD Micro logo
2
14
9001
1-141
Screw 10-32 x 1.25
4
15
90002-146
P/Head Noir Molded, P
.P
.
2
16
76000-168
T
ubing D/Char
ge, 3/8 x 5FT
2
76000-169
T
ubing D/Char
ge, 1/4 x 5FT
.
2
17
C-406
VT
-17N
Diaphragm S/A
2.0 17N,
V
iton/PTFE
2
C-406T
-17N
Diaphragm S/A
2.0 17N, EP/PTFE
2
R-106VT
-17N
Diaphragm S/A
1.6 17N,
V
iton/PTFE
2
R-106T
-17N
Diaphragm S/A
1.6 17N, EP/PTFE
2
18
90006-022
Return Spring C-1700N
4
19
76000-288
Stirr
-up
2
20
90002-001
Slide Bearing
4
21
90001-132
Of
fset Cam #1 .125”
2
90001-133
Of
fset Cam #2 .055”
2
90001-134
Of
fset Cam #3 .187”
2
90001-141
Of
fset Cam #4 .100”
2
22
90002-017
Dial Knob
2
23
90012-220
Label,
T
op Cover
1
24
9001
1-168
Screw #6 x .62 PH oval ‘A
’
4
25
76000-938
T
op Cover
1
26
9001
1-121
Thumb Screw 6-32 x 1.125
2
27
90006-599
Gasket,
T
op Cover
1
28
90004-005
Bearing,
T
op Cover
1
29
70000-131
Drive Cam S/A
#1 .125”
1
70000-133
Drive Cam S/A
#2 .055”
1
70000-132
Drive Cam S/A
#3 .187”
1
70000-722
Drive Cam S/A
#4 .100”
1
30
9001
1-014
Spacer
, Rotor
1
31
9001
1-122
Screw 10-32 x .50 PHL
P
AN
4
32
76000-937
Motor Mount, Lar
ge Diaphragm
1
33
90008-138
Plug .312 Hole Black
1
34
90002-106
Clamp C-17N
W
all Mount
1
35
9001
1-122
Screw 10-32 x .50 PHL
P
AN
2
36
90006-597
Gasket, Motor Mount
1
37
76000-630
Slide Clamp
2
38
76000-939
Motor Cover C-17N
1
15V
1
76000-940
Motor Cover C-17N
220/230V
1
39
90003-513
Bumper Feet
4
40
70000-589
Connector Liq-T
ite w/nut
1
41
90010-1
10
Cord 18/3 SJTW/A
1
15v
1
90010-128
Cord 18/3 SJTW/A
European BLK
1
90010-133
Cord 18/3 SJTW/A
230v BLK
1
42
71000-133
Cover
, Junction Box with Gasket and Label
1
43
90007-515
Bushing, Junction Box Connector
, Alum.
1
44
76000-522
Junction Box,
V
alox
1
45
9001
1-129
Screw
, Cover
, 6-32 X .25 Phil Pan SS Black
2
46
90006-598
Fan, 1.80” Diameter
, Alum.
1
47
9001
1-022
Screw
, Motor
, 8-32 X 2.5” Phillips Steel
2
48
70000-028
Bearing Bracket
W
ith Bearing
2
49
70000-027
Rotor
Assembly
W
ith Shaft
And Spacers
1
50
70000-018
Stator S/A, 1
15V60Hz Standard Blue-Black
1
70000-019
Stator S/A, 1
15V60Hz
Thermal Blue-Y
ellow
1
71000-019
Stator S/A, 220V50Hz Standard Brown-Black
1
71000-020
Stator S/A, 220V50Hz
Thermal Brown-Y
ellow
1
70000-020
Stator S/A, 230V60Hz Standard Red-Black
1
70000-021
Stator S/A, 230V60Hz
Thermal Red-Y
ellow
1
70000-072
Stator S/A, 24V60Hz Standard Blue-White
1
51
9001
1-024
Ground Screw 8-32 x .25 Hex SL
ST
1
52
90010-127
Lead
W
ire, ground, Green
1
53
9001
1-078
W
asher
, Ground Screw
, #8 Intrl/Star
1
54
71000-268
Gearbox, 14 RPM
1
71000-269
Gearbox, 30 RPM
1
71000-270
Gearbox, 45 RPM
1
71000-271
Gearbox, 60 RPM
1
71000-272
Gearbox, 125 RPM
1
55
70000-439
Injection
V
alve S/A
37T
VIT
1/2 PSI
1
(N/s)
90010-153
Cycle
T
imer 5 Sec. 24V
-1
15V
-230V
50/60 Hz
1
(N/s)
90010-151
Cycle
T
imer 1 Min. 24V
-1
15V
-230V
50/60 Hz
1
(N/s)
90010-152
Cycle
T
imer 10 Min. 24V
-1
15V
-230V
50/60 Hz
1
