CAUTION: Proper eye and skin protection must be
worn when installing and servicing the pump.
Page 9
Discharge Tube
(Rigid P.E.)
Outlet Adapter
Tube Nut
Inlet Adapter
Tube Nut
Suction Tubing
(clear PVC)
Manual
Stroke length
Adjustment knob
Footvalve
CAUTION
ADJUST WHILE RUNNING
DISCHARGE LINES MAY BE
UNDER HIGH PRESSURE. USE
CARE TO PROTECT YOURSELF
WHEN DISCONNECTING.
MAX
MIN
1 2
3
4
5
6
7
8 9
LOOSEN THE LOCK SCREW
TURN KNOB TO DESIRED SETTING
RE-TIGHTEN THE LOCK SCREW
Tube Nut
Injection
Check valve
Ceramic Weight
Lock Screw
Pump Head
Install
upward
C-1100V
RUN
STANDBY
RUN FIELD DIGIT MODE
PROGRAM
STAND-BY
PRIME
MINIMUM
MAXIMUM
INPUT MODES
1 - MANUAL 2 - 4-20mA 3 - 0-10VDC 4 - PULSE (Hz)
PROGRAM
RESET SERVICE
PRIME
DISPLAY
VARIABLE SPEED PUMP
% SPEED VDC
SERVICE ALARM
mA Hz
