26
C
ONTINUITY
AND
W
IRING
D
IAGRAMS
Model
926003
Item Part No. Qty. Description
1
00432500
1
Light, Halogen Assembly
2
07500015
2
Warmer, Hand with Terminal (Recommend Fast Drying Epoxy for Installation)
3
00432300
1
Harness, Wire Light - Hand Warmer
4
02485700
1
Switch, On/Off Hand Warmer
1
D.C. CHARGE
A.C. LIGHTING
HEAD LIGHT
BLACK
RED
2
YELLOW
YELLOW
BROWN/ORANGE
YELLOW
BLACK
1
1
2
2
1
1
2
2
BR
O
WN/ORANGE
HAND WARMER
SWITCH
HAND
WARMERS
LEFT
RIGHT
ENGINE
BLACK
GROUND
4
1
2
3
4
1
2
3
PS0830
1
2
The diagrams below show the various states of connection for electrical components.
The solid lines on switches show continuity.
NOTE: All switches are viewed from the rear.
Hand Warmer Switch
(02485700)
HAND WARMER
OFF
HAND WARMER
ON
PS0820
