Page 11: Installation is complete 11
Installation Manual
INSERT TAMPER PLUGS
After programming the endpoint is complete and for security purposes, insert the four (4) red tamper plugs (supplied) into
the screw holes and push them in until flush See
Tamper plugs
Figure 19: Tamper plug placement
INSTALLATION IS COMPLETE
Installation of the ORION endpoint for a SENSUS 415 gas meter with dial index is now complete
Page 11
July 2014
