Audient ASP8024 Dual Layer Control Module - Manual (Page 30)

Page -30- © Audient Ltd
Pan Mode + Assign
By pressing the assign key (30) when in
pan mode, the encoders provide access to
several channel functions including routing.
This is very useful for setting up inputs
for recording or bussing architecture
when mixing. First a channel must be
selected using the large green channel select
switches (18).
Input assigns are set on page one. Use the
page keys (26) to access page two where
polarity reverse can be toggled on and
off.
Assigning channel inputs, outputs or enabling software
monitoring can be achieved on page one of
pan + assign mode.
Control Surface Functions
