Alicat PCU Portable Calibration Unit - Manual (Page 4)

Table of Contents Page
Additional Information
Flow Conversion Table
26
Option: Totalizing Mode Screen 27
Table of Figures
Figure 1. PCU Controls and Connections
6
Figure 2. Main Mode Display 7
Figure 3. Select Menu Display 9
Figure 4. Gas Select Display 9
Figure 5. Communication Select Display 10
Figure 6. Manufacturer Data Displays 11
Figure 7. Miscellaneous Display 12
