Electrical data, Condensers, Outd oo r outd oo r – Airedale Air Cooled Condensers R410A User Manual
Page 23: Condenser, Interconnecting wiring
CR12-165
CONDENSERS
Condenser
23
Technical Manual :6666879 1.1.0 02_2013
/2012
Electrical Data
Condenser
CR12
CR16
CR22
CR26
CR30
CR35
CR50
CR60
CR65
Unit Data
(1)
Nominal Run Amps
A
1.2
1.2
2.6
1.7
2.6
1.7
5.2
3.3
5.2
Maximum Start Amps
A
4.1
4.1
9.2
6.1
9.2
6.1
18.3
12.2
18.3
Recommended Mains Fuse
A
6
6
6
6
6
6
10
6
10
Max Mains Cable Incoming
mm²
6
6
6
6
6
6
6
6
6
Mains Supply 50Hz
230V/1Ph
400V/3Ph
230V/1Ph
400V/3Ph
230V/1Ph
400V/3Ph
230V/1Ph
Fan - Per Fan
Quantity
1
1
1
1
1
1
2
2
2
Motor Size
kW
0.27
0.27
0.6
0.88
0.6
0.88
0.6
0.88
0.6
Full Load Amps
A
1.2
1.2
2.6
1.7
2.6
1.7
2.6
1.7
2.6
Locked Rotor Amps
A
4.1
4.1
9.2
6.1
9.2
6.1
9.2
6.1
9.2
OPTIONAL EXTRAS
Short Case Axial Fan - Per Fan
Quantity
1
1
1
1
1
1
2
2
2
Motor Size
kW
0.61
0.61
1.4
1.94
1.4
1.94
1.4
1.94
1.4
Full Load Amps
A
2.8
2.8
6
3.4
6
3.4
6
3.4
6
Locked Rotor Amps
A
7
7
18
11.9
18
11.9
18
11.9
18
EC Condenser Fan - Per Fan
Quantity
1
1
1
1
1
1
2
2
2
Motor Size
kW
0.69
0.69
0.73
1.68
0.73
1.68
0.73
1.68
0.73
Full Load Amps
A
3.1
3.1
3.3
2.6
3.3
2.6
3.3
2.6
3.3
Condenser
CR75
CR80
CR95
CR105
CR130
CR140
CR165
Unit Data
(1)
Nominal Run Amps
A
3.3
7.86
4.95
7.86
4.95
10.48
6.6
Maximum Start Amps
A
12.2
27.5
18.3
27.5
18.3
36.7
24.4
Recommended Mains Fuse
A
6
16
10
16
10
16
10
Max Mains Cable Incoming
mm²
6
6
6
6
6
6
6
Mains Supply 50Hz
400V/3Ph
230V/1Ph
400V/3Ph
230V/1Ph
400V/3Ph
230V/1Ph
400V/3Ph
Fan - Per Fan
Quantity
2
3
3
3
3
4
4
Motor Size
kW
0.88
0.6
0.88
0.6
0.88
0.6
0.88
Full Load Amps
A
1.65
2.62
1.65
2.62
1.65
2.62
1.65
Locked Rotor Amps
A
6.1
9.17
6.1
9.17
6.1
9.17
6.1
OPTIONAL EXTRAS
Short Case Axial Fan - Per Fan
Quantity
2
3
3
3
3
4
4
Motor Size
kW
1.94
1.4
1.94
1.4
1.94
1.4
1.94
Full Load Amps
A
3.4
6
3.4
6
3.4
6
3.4
Locked Rotor Amps
A
11.9
18
11.9
18
11.9
18
11.9
EC Condenser Fan - Per Fan
Quantity
2
3
3
3
3
4
4
Motor Size
kW
1.68
0.73
1.68
0.73
1.68
0.73
1.68
Full Load Amps
A
2.6
3.3
2.6
3.3
2.6
3.3
2.6
Interconnecting
Wiring
(CR26,35,60,75,95,130,165)
L1
Mains Incoming 400V / 3Ph + N / 50Hz
L2
L3
N
PE
Interconnecting wiring
(CR12,16,22,30,50,60,65,80,105,140)
L1
Mains Incoming 230V / 1Ph + N / 50Hz
N
PE
(1)
Nominal data based on 35°C ambient and a 50°C mean condensing temperature and using standard fan.
