CR12-165
CONDENSERS
Condenser
11
Technical Manual :6666879 1.1.0 02_2013
/2012
Horizontal case size 3 (2 Fans)
DIMENSIONS (mm)
WEIGHTS (kg)
Standard Fan
Standard AC Fan
Optional EC Fan
Optional SCAF
A
B
C
D
E
CR50
2184
1167
1000
2121
700
132
145
154
CR60
2184
1167
1000
2121
700
165
188
159
CR65
2184
1167
1000
2121
700
162
175
184
CR75
2184
1167
1000
2121
700
195
218
189
Vertical case size 3 (2 Fans)
DIMENSIONS (mm)
WEIGHTS (kg)
Standard Fan
Fan Options
Standard AC
Fan
Optional EC
Fan
Optional
SCAF
SCAF
EC
A
B
C
D
E
B
B
CR50
2184
1090
1167
2124
1107
1130
1127
132
145
154
CR60
2184
1155
1167
2124
1107
1140
1170
165
188
159
CR65
2184
1090
1167
2124
1107
1130
1127
162
175
184
CR75
2184
1155
1167
2124
1107
1140
1170
195
218
189
