Mechanical Data- Condensers
CR130 CR140 CR165
Total Heat of Rejection CR (1) kW 149.7 150.1 195.7
Dimensions - Horizontal (2)
H x W x L mm 1167 x 1000 x 3565 1167 x 1000 x 4641 1167 x 1000 x 4641
Dimensions - Vertical (2)
H x W x L mm 1155 x 1167 x 3565 1090 x 1167 x 4641 1155 x 1167 x 4641
Weight
Machine kg 310 349 415
Construction
Material/Colour Galvanised Sheet Steel, Epoxy Baked Powder Paint - Light Grey (RAL 7035)
Condenser Air Cooled - Rifled Copper Tube/Turbulated Aluminium Fins
Dry Cooler Air Cooled - Copper Tube/Turbulated Aluminium Fins
Total Face Area m² 3.63 4.8 4.8
Nominal Airflow m³/s 9.3 8.7 12.4
Discharge -H Horizontal or -V Vertical (Please Specify at Order)
Fan & Motor Axial
Quantity 3 4 4
Diameter mm 710 630 710
Maximum Speed rpm 930 895 930
Refrigeration - CR Single Circuit
Refrigerant Type R410A
Holding Charge Inert Gas
Coil Volume l 36.6 TBC TBC
Refrigerant Charge (3) kg 16.7 TBC TBC
Dry Cooler
Internal Water Volume L 43.2 55.9 55.9
Water flowrate l/s 3.4 3.5 4.6
Pressure Drop kPa 53 62 94
Connections
Liquid Line - Sweat in 7/8 7/8 7/8
Discharge Line - Sweat in 1 3/8 1 3/8 1 3/8
OPTIONAL EXTRAS
Short Case Axial Fan Designed to 75 Pa ESP
Dimensions – Horizontal
H x W x L mm 1140 x 1000 x 3565 1167 x 1000 x 4641 1167 x 1000 x 4641
Dimensions – Vertical
H x W x L mm 1140 x 1167 x 3565 1130 x 1167 x 4641 1140 x 1167 x 4641
Weight
Machine kg 345 394 404
EC Fan
Dimensions – Horizontal
H x W x L mm 1167 x 1000 x 3565 1167 x 1000 x 4641 1167 x 1000 x 4641
Dimensions – Vertical
H x W x L mm 1170 x 1167 x 3565 1127 x 1167 x 4641 1170 x 1167 x 4641
Weight
Machine kg 301 375 462
(1) Nominal data based on 35°C ambient and a 50°C mean condensing temperature and using standard fan.
(2) Overall dimensions for clearance; refer to
Dimensional & Installation Data , for detail.
(3) For guidance only.
