1090 Technical Manual P a g e | 15
SIMULATE ACCURACY (0.1 deg C/F resolution)
THERMOCOUPLE
TYPE
TEMPERATURE
RANGE deg C
ACCURACY
Deg C
J -210 to 150
150 to 1200
0.15
0.3
K -270 to 190
190 to 1250
0.5
0.4
T -200 to 150
150 to 400
0.4
0.5
R -50 to 800
800 to 1750
0.8
2.0
S -50 to 850
850 to 1750
0.9
2.0
B 100 to 1200
1200 to 1800
2.0
3.0
N -270 to 260
260 to 1300
0.5
1.0
E -50 to 1000 0.3
An additional correction representing the equivalent 1µV should be allowed for stray
thermal emf effects.
Millivolt Measure 0 to +/- 30mV
Resolution: 10µVAccuracy:
± 0.05% of f.s. ± 1 digit
Input resistance 100K Ohms
Milliamp Measure 0 to +/- 60mA
Resolution 20µA
Accuracy ± 0.05% of f.s. ± 1 digit
Input resistance 0.5 ohms
