D B - 3 a n d D B - 3 A O P E R A T O R ’ S M A N U A L
P A G E 22
ADDITIONAL INFORMATION
Insert Blocks
Insert blocks are made of aluminium alloy and must be ordered
separately from the heater units. The following blocks are available
from Techne:
Part Tube Size Number of Holes Size
F3501 Plain block None 95 x 76 x 51
F3502 6mm 30 95 x 76 x 51
F3503 10mm 20 95 x 76 x 51
F3504 12mm 20 95 x 76 x 51
F3505 13mm 20 95 x 76 x 51
F3506 15mm 12 95 x 76 x 51
F3507 16mm 12 95 x 76 x 51
F3508 19mm 8 95 x 76 x 51
F3509 25mm 6 95 x 76 x 51
F3510 10mm cuvettes 2 channels 95 x 76 x 51
F4460 Plain block Thermometer hole only 95 x 76 x 51
F4461 9mm/7mm 10/20 95 x 76 x 51
F4462 24mm 6 95 x 76 x 51
F4463 26mm 6 95 x 76 x 51
F4464 1.5ml Eppendorf 20 95 x 76 x 51
F4465 0.5ml Eppendorf 30 95 x 76 x 51
F4466 Plastic half block Plain 95 x 37 x 50
F4470 2 ml Eppendorf 20 95 x 76 x 51
F4471 0.2ml 72 95 x 76 x 51
