ABOUT YOUR MT110-100/102 2
MT110-100/102
16-In 8-Out Audio Matrix Switcher Card
The MT110-100 and MT110-102 are balanced
input Audio Matrix Switching Cards. Each card
allows any input to be independently switched to
any of the outputs. All inputs and outputs can be
wired for unbalanced or balanced audio, allowing
longer cable runs and superior noise resistance.
These cards utilize AC coupling on their inputs for
ideal signal transfer characteristics. Switching is
controlled with easy-to-use ASCII commands from
a control system or computer connected to the
RS-232 port of a MultiTasker™ enclosure. Each
card consumes two slots in a MultiTasker™
enclosure, and all input and output connections are
accomplished via captive screw terminal blocks.
Although designated as a 16x8 matrix switcher, the
MT110-100/102 can be used in a variety of ways to
provide different capabilities. For example, one
16x8 card can handle mono audio while two 16x8
cards handle stereo audio, or a single 16x8 card
can be used to create an 8x4 stereo audio matrix.
Similarly, a single 16x8 card can be used to provide
two 4x2 stereo audio matrix switchers. The
MT110-100 is a standard matrix switcher, whereas
the MT110-102 has individual volume trim control
on each output.
The HelpInside™ feature allows programmers to
have access to command structures and control of
the MT110-100/102 from any terminal using the
[HELP] command. In conjunction with Altinex’s
unique command structure, HelpInside™ provides
easier-than-ever control of MultiTasker™ cards
with simple keyboard commands. No typing of long
keyboard strings is necessary.
TECHNICAL SPECIFICATIONS 3
FEATURES/DESCRIPTION MT110-100/102
GENERAL
Inputs
Input Connectors
(8) 5-pin Terminal
Blocks
Outputs
Output Connectors
(4) 5-pin Terminal
Blocks
Compatibility Stereo or Mono Audio
Table 1. MT110-100/102 General
MECHANICAL MT110-100/102
Basic Enclosure Slots
Required
Two
Weight 1.0 lb (0.45 kg)
Connector Panel Black
T° Operating 10°C-35°C
T° Maximum 0 to 50°C
Humidity 90% non-condensing
MTBF (calc.) 40,000 hrs
Table 2. MT110-100/102 Mechanical
ELECTRICAL MT110-100/102
Input Signals
Max Level
0 dBu
Impedance 10k Ohms
Audio Throughput
Gain
0 dB unbalanced,
6dB balanced
Frequency Response
10 Hz to 20 kHz
(+/- 0.05 dB)
Noise Floor -100 dB @ 20 kHz
CMRR
>80 dB, 10 Hz to 20
kHz
Output Signals
Level
1V p-p
Impedance Low – drives 600 Ohms
Gain 0 dB
Power (from MT100-100)
+6V
160mA
-6V 125mA
Total 1.7 Watts
Table 3. MT110-100/102 Electrical
