Example:
In order to display the RS-232 commands
available for the MT110-102 card in slot 2, send
the command [HELPC2]. The commands along
with a brief description will be displayed in the
terminal window.
7.3. SUMMARY OF COMMANDS
Card Commands
1) [VER] Receives software version
2) [C] Receives status of the card
3) [CnS] Save card settings
4) [?] Show system cards
5) [?C] Show card information
6) [STA1] Enable auto feedback
7) [STA0] Disable auto feedback
8) [ON] Turn on one or more outputs
9) [OFF] Turn off one or more outputs
10) […S] Save the command being sent
11) […F] Show command feedback
12) […P] Sets the path, preload for [SW]
13) [SW] Switch preloaded output buffer
14) [IO] Connect an input to output
15) [IO*] Connect an input to all outputs
16) [CLR] Reset card to default values
17) [OSI] Set input offset
18) [OSO] Set output offset
19) [FBD] Feedback delay on/off
ID Commands
20) [RSI] Reset Card IDs
21) [SIDn] Set all Card IDs
22) [SIDnCi] Set one Card ID
23) [SID+] Set Card ID offset
24) [RSN] Read Card slot number
Group Commands
25) [WR] Groups multiple cards
26) [RMC] Remove members from group
27) [RMG] Delete group
28) [RD] Displays group members
Volume/Matrix Commands
29) [TEST] Test internal memory ICs
30) [VLO] Set absolute output volume
31) [SEL] Select input volume to adjust
32) [ + ] Increment volume
33) [ - ] Decrement volume
34) [RUP] Ramp UP to max (32)
35) [RDN] Ramp DOWN to min (0)
36) [RUPm] Ramp volume UP to max (32)
37) [RUPm=] Ramp volume UP to a value
38) [RDNm] Ramp volume DOWN to min (0)
39) [RDNm=] Ramp volume DOWN to a value
40) [RST] Stop ramping
41) [RAMP] Display ramp rate
42) [RAMP=] Set ramp rate
43) [MUT0] Output Volume ON
44) [MUT1] Output Volume OFF
45) [MAT] Matrix Configuration
46) [HELP] Display available commands
