Revo RECDH36-2 - Manual (Page 5)

1
The camera provides high-quality images using Sony CCD technology especially
applications. designed for closed-circuit television (CCTV) and security surveillance
Features:
INTRODUCTION
TM Technology High resolution and high performance Sony Supe r HAD
Excellent picture quality
600 lines(Color) of resolution
0.1 lux(Color), 0.04 lux(B/W) @ F.1.2 Sensitivity
shutter modes Auto electronic shutter [1/60(1/50) ~ 1/100,000] and manual electronic
OSD (On Screen Display)
Auto and manual white balance modes
DWDR
OSD Font Color ( 16 Color)
BLC (Back Light Compensation)
Day&Night (Auto / DAY / NIGHT / EXT)
Private Mask (8 position, 16 Colors)
AGC (Auto Gain Control)
MIRROR (ON/OFF)
VIDEO OUT BNC
Motion Detection(4 point)
HLC (High Light Compensation)
DPC (Dead Pixel Cancellation)
2.6~6
DC12V +/- 10%
Use Certified / Listed Class 2 power source only
Test monitor Output
4-9mm A/I Varifocal Lens F1.6~2.4
mm A/I Varifocal Lens F1.6~2.4
3.6 mm Fixed Lens F3.0
IMPORTANT : The user of this camera is responsible for
checking and complying with local, state, and federal laws
and statutes concerning the recording and monitoring of
audio signals.
(D&N Lens option)
(D&N Lens option)
