CONNECTING THE 15 PIN SIGNAL CABLE AND POWER CORD

① Turn off the DVR and monitor.
② Connect the 15 pin signal cable to the output port of the DVR and

monitor.

③ Connect the audio cable to the output port of the sound DVR.
④ Plug the power cord into the AC receptacle located on the back of the

monitor.

15 pin Signal
Cable

Audio Cable

Power Cord
