English - 12
Panel Size 19-inch(48 cm) diagonal
Pixel Pitch 0.2835(H)mm x 0.2835(V) mm
Viewing Angle 80°(Right/Left)
80°(down)
Contrast Ratio 1000:1 contrast ratio (typ)
Brightness 300cd/m 2 brightness (typ)
Response Time 5msec
Color Filter RGB vertical stripe
Synchronization Horizontal 30 - 80 Hz
Vertical 56 - 77 Hz
Video Bandwidth 140 MHz
Max Resolution 1440 x 900 @ 75Hz
Optimal Resolution 1440 x 900 @ 75Hz
Colors 16.7 M Colors
Display Area 408.24mm(H) x 255.15 mm(V)
PC Input Signal Sync H/V separate (TTL)
Video 15 pin mini D-sub(Analog RGB)
Speaker Max. Output 6W (Left 3W + Right 3W)
Plug and Play VESA DDC Compatible
Power Source 100 - 240 Vac
Power Consumption 35 W
Dimension-W x H x D 457(w) X 377(h) X 202(d) mm
457(w) X 309(h) X 62(d) mm
Weight-net/gross 4.3Kg / 6.0Kg (9.5 / 13.2 Lbs)]
Power Saving EPA, VESA DPMS, Nutek Compliant
Tilt Range 1° forward, 15° backward
Operating Temperature 10 ~ 40°C /50 ~ 104°F
<19 inch wide LCD>
The LCD panel may have some defective pixels (e.g. slightly light or dark) due to a
characteristic of the LCD panel. But there is no defect in your LCD product itself.
The specification can be changed without any prior notice to improve the quality of the product.
SPECIFICA SPECIFICA TIONS TIONS
