Up dimensions: 70 amp frame – Precision Control Systems 1032 User Manual

Page 6

background image

Model 1032

4 of 9

Part No. 5000095-1011-6 6/13/2003

6.00

9.25

8.00

9.00

8.00

Figure 4. Mounting dimensions of 70 Amp model 1032.

Figure 5. End view of 70 amp model 1032.

0.32 wide X

0.45 long (4)

UP

DIMENSIONS: 70 Amp Frame
