Options and Accessories
Lamps -
Lamps for the Model E4 are included with the heater. Table 2-2 displays available lamps for
replacement ordering.
(*) Standard lamp that ships in heater
(**) Lamps are for Horizontal Operation Only
Quartz Liner -
A quartz liner can be provided to protect the reflectors in the heater from contaminants, to
maintain the reflectors at their maximum efficiency. It has a 2.24 inch (57 mm) outer diameter
and a 2.09 inch (53 mm) inner diameter.
Observation Window -
A 0.5 inch diameter window (W) with a quartz cover can be provided in the center of the
chamber side wall, to permit product viewing. With the quartz cover removed, product
temperature can be measured with a suitable optical pyrometer. The observation window is not
available on models ordered with four purging ports. See Figure 3 for Window placement.
Purging Ports -
Purging ports can be provided on two (P) or four (PP) opposing sides of the chamber wall. This
feature allows the heating environment to be force-cooled or inert gas-purged. Purging ports
will not function with a quartz liner installed. See Figure 3 for purge port placement.
Table 2-2: Lamps
Model (P/N)
Heated
Length
Volts
Watts
Lamp Description
057550-002 2
Inches 120
500
Q500T3/CL
057550-003
2 Inches
120
1000
Q1000T3/4CL (*)
057541-001
5 Inches
120
500
500T3/CL (*)
057550-004
6 Inches
120
1500
Q1500T3/CL (*)
057544-002 10
Inches 240
1000
1000/T3/2CL/HT
057544-005
10 Inches
240
2000
2000/T3/CL/HT (*)
057541-004 16
Inches 240
1600
1600T3/CL
057541-008
16 Inches
240
3000
3000T3/CL (*) (**)
057541-005
25 Inches
480
2500
2500T3/CL (**)
057549-001
25 Inches
480
2500
2500T3/VB/CL (*)
057544-008
25 Inches
600
5000
5MT3/1CL/HT (**)
057541-006
38 Inches
570
3800
3800T3/CL (**)
057549-002
38 Inches
570
3800
3800T3/VB/CL (*)
