4.1 SETTING HOURS AND MINUTES
Press HOUR and MIN to set desired time. Press
EVENT to set desired event (ON/OFF) and then
press ENTER. The display will show:
Follow the same procedures above to set more
schedule entries for CH1. Press CH1/CH2 key to
program schedule for CH2.
5.0 REVIEW, MODIFY AND DELETE
Press MODE to advance to any of the following
MODES:
1. CLOCK MODE: Press HOUR and MIN to mod-
ify existing settings. Press ENTER.
2. DATE MODE: Press MONTH, DATE and YEAR
to modify existing settings. Press ENTER. DAY
is automatically adjusted.
3. DST Daylight Saving Time: To review press
ENTER. To modify press MONTH, DATE and
DAY to change existing setting. Press ENTER.
4. SCHEDULE MODE: Press HOUR, MIN and
EVENT to modify time settings. Press DEL to
delete. Press ENTER after each modification.
5. RUN MODE: The time, day, seconds, the load
status and AUTO is displayed.
6.0 OVERRIDE
OVR1/OVR2 is effective in the AUTO mode and
the manual mode. OVR on the AUTO mode is
effective until the next event. OVR on the manual
mode is effective indefinitely.
6
CLK DATE SCH
CH1
AUTO MAN
PROGRAMMING YOUR E201B
NOTE: AFTER MAKING ANY CHANGES TO THE
PROGRAM, PRESS MODE TO GO TO RUN
MODE AND THEN PRESS EVENT TO UPDATE
THE LOAD STATUS.
1.0 TO SET CLOCK
Press HOUR and MIN to advance to the present
hour and mins. Check AM/PM, and press ENTER.
1.1 TO MODIFY CLOCK
Press MODE until the display shows: CLK. Press
HOUR and MIN. to modify clock and press
ENTER.
2.0 TO SET DATE
If you are setting for the first time, display will
show:
3
MO TU WE TH FR SA SU ASTRO
CH1 MOM AM PM OFFSET CH2
CLK DATE SCH AUTO MAN
MO TU WE TH FR SA SU ASTRO
CLK DATE SCH AUTO MAN
E101B 4/3/07 9:52 PM Page 9
AT POWER UP:
When powering up the unit for the first time,
12:00 will flash on the display. NOTE: Allow
1-2 minutes for the supercap to charge
before any display is shown.
