Metex MS Series Conductivity Cells User Manual
Page 4
Page
2
2.0
SPECIFICATIONS
CELL CONSTANTS: 0.01 to 50
THREADED SIZE: 3/4” NPT
TEMPERATURE COMPENSATION: Automatic 0-120°C (32-248°F)
CABLE LENGTH: 4m (13ft)
INSERTION LENGTH: Variable (see Section 4.1.5)
WETTED MATERIALS:
MS_P: Graphite, Epoxy, EPDM, CPVC
MS_S: Graphite, Epoxy, Polypropylene, 316 stainless steel
SAFETY FEATURE: Shoulder on cells provides an integral
safety stop
TEMPERATURE and PRESSURE:
Type
Max. Press. (psi)
Max. Temp. (°C)
P
S
50
100
150
250
60
50
20
120
