Martel Electronics OEM1B - Manual

PRODUCT DESCRIPTION
The OEM 1B uses the latest miniaturisation techniques to produce a very compact 3 ½ digit LCD voltmeter. It is
designed to be a drop-in component in most medium and high volume applications, ranging from personal
instrumentation and integral sensor indicators to measurement probes. The meter features 8mm digit height, 3
decimal points, auto-polarity, auto-zero, 200mV full scale reading and a very low current consumption.
Connection to the module is via two dual in line rows of pins.
FEATURES
• 8
• 200mV d.c. Full Scale Reading
• 150 A @ 7.5 to 14V Operation
•
• Selectable
• Very Compact Design mm (0.31") Digit Height
Decimal Points
µ
Auto-zero and Auto-polarity
TYPICAL APPLICATIONS
• Personal Gas Monitoring
• Medical Instruments
• Measurement Probes
• Hand held instruments
ORDERING INFORMATION
Stock Number
Standard Meter
OEM 1B
LASCAR ELECTRONICS LTD.
MODULE HOUSE
WHITEPARISH
WILTSHIRE
SP5 2SJ
UK
TEL: +44 (1794) 884567
FAX: +44 (1794) 884616
E-mail: [email protected]
LASCAR ELECTRONICS (HK) LIMITED
FLAT C, 5/FL., LUCKY FTY. BLDG.
63-65 HUNG TO ROAD
KWUN TONG
KOWLOON
HONG KONG
TEL: +852 2797 3219
FAX: +852 2343 6187
E-mail: [email protected]
OEM 1B
3½ Digit LCD Voltmeter Module
SAFETY
To comply with the Low Voltage Directive (LVD 93/68/EEC), input voltages to the module’s pins must not exceed
60Vdc. The user must ensure that the incorporation of the panel meter into the user’s equipment conforms to the
relevant sections of BS EN 61010 (Safety Requirements for Electrical Equipment for Measuring, Control and
Laboratory Use).
Page 2 of 4 Page 2 of 4
Page 1 of 4 www.lascarelectronics.com
ELECTRICAL SPECIFICATIONS
Specification Min. Typ. Max. Unit
Accuracy (overall error) * 0.1 % (±1 count)
Linearity 1 count
Sample rate 2.5 samples/sec
Operating temperature range 0 50 °C
Temperature stability 100 ppm/°C
Supply voltage (V+ to V-)
Input leakage current (Vin = 0V) 1 10 pA
+
7.5 9 14** V d.c.
Supply current 150 A µ
LASCAR ELECTRONICS INC.
3750 West 26th Street
Erie
PA 16506
USA
TEL: +1 (814) 835 0621
FAX: +1 (814) 838 8141
E-mail: [email protected]
* To ensure maximum accuracy, re-calibrate periodically.
** Operation of the meter beyond the maximum supply voltage rating may cause permanent damage to the meter.
Unless otherwise noted, specifications apply at T =25°C, V =5Vd.c. (f =48kHz) and are tested with the module configured for floating input
mode.
