Martel Electronics DPM750S-BL User Manual
Dpm 750s-bl, Features, Ordering information

FEATURES
• 12.7
• 200mV d.c. Full Scale Reading
• 3.0 to 7.5V or 6.0 to 15V d.c. Operation
•
•
•
• Bandgap Reference
mm (0.5") Digit Height
Programmable Decimal Points
LED Backlighting (30mA @ 5V typ.)
• Low Battery Warning
Auto-zero and Auto-polarity
ORDERING INFORMATION
Stock Number
Standard Meter
DPM 750S-BL
IP67 / NEMA 4X Bezel
BEZ 700-IP
ELECTRICAL SPECIFICATIONS
Page 2 of 4
Page 2 of 4
Page 1 of 4
www.lascarelectronics.com
Specification
Min.
Typ.
Max.
Unit
Accuracy (overall error) *
0.1
% (±1 count)
Linearity
±1
count
Sample rate
2.5
samples/sec
Operating temperature range
0
50
°C
Temperature stability
50
ppm/°C
Supply voltage
V+ to GND configuration
3
5
7.5
V d.c.
350
A
Backlight supply current @ 5V d.c.
30
mA
Input leakage current (Vin = 0V)
1
10
pA
V+ to V-
configuration
6
9
15
V d.c.
Supply current
V+ to GND configuration
500
A
V+ to V-
configuration
Backlight supply voltage
4.75
5.0
**
V d.c.
µ
µ
50 ***
° °
C F
µ
A
mV
k
Ω
MH
z
LASCAR ELECTRONICS LTD.
MODULE HOUSE
WHITEPARISH
WILTSHIRE
SP5 2SJ
UK
TEL: +44 (1794) 884567
FAX: +44 (1794) 884616
E-mail: [email protected]
LASCAR ELECTRONICS (HK) LIMITED
FLAT C, 5/FL., LUCKY FTY. BLDG.
63-65 HUNG TO ROAD
KWUN TONG
KOWLOON
HONG KONG
TEL: +852 2797 3219
FAX: +852 2343 6187
E-mail: [email protected]
SAFETY
To comply with the Low Voltage Directive (LVD 93/68/EEC), input voltages to the module’s pins must not exceed
60Vdc. The user must ensure that the incorporation of the panel meter into the user’s equipment conforms to the
relevant sections of BS EN 61010 (Safety Requirements for Electrical Equipment for Measuring, Control and
Laboratory Use).
TYPICAL APPLICATIONS
• Precision Instrumentation Systems
• Power Supply Monitoring
• Test Boxes
• Panel-Mount Indication
• Low Power Voltage Measurement
DPM 750S-BL
3½ Digit Backlit LCD Voltmeter Module
The DPM 750S-BL features a 200mV d.c. measurement range with auto-zero and auto-polarity. Decimal points are
user selectable.
LED backlighting ensures excellent readability under low light conditions. The module's
The meter features a negative rail generator which enables the meter to measure a signal referenced to
its own power supply GND. A low drift bandgap reference circuit ensures accurate readings over a wide temperature
range.
low cost means it will
suit high and low volume applications. This module is supplied with a plastic mounting bezel. A waterproof seal to
IP67 / NEMA 4X is achievable, using the optional BEZ 700-IP bezel.
* To ensure maximum accuracy, re-calibrate periodically.
** An external series resistor is required above 5V, see Applications.
*** This specification linearly derates to 30mA @ 50°C.
