Martel Electronics V1 - Manual (Page 2)

DIMENSIONS
All dimensions in mm (inches)
PANEL FITTING
PIN CONFIGURATION
(rear view)
FUNCTIONAL BLOCK DIAGRAM
Page 2 of 4 Page 2 of 4
Vref
A/D +
_
INHI
COM
INLO
XDP
DP3 2 1
V+
V-
CAL
Panel
Bezel
Meter
1 2 4
Fixing Clip
Fastener
3
V 1
3½ Digit LCD Voltmeter Module
1 5
4 8
REAR VIEW
V+
V-
INHI
INLO
XDP
DP1
DP2
DP3
L1
CAL
30.0 (1.18)
23.0 (0.91)
dia 2.5 (0.1)
38.0 (1.50)
21.0 (0.83)
14.0
(0.55)
8.0
(0.31)
2.54
(0.1)
5.5 (0.22)
1.6 (0.06)
Panel thickness: 1.0 - 3.0
(0.04 - 0.12)
38.0 (1.50)
18.0
(0.71)
15.0
(0.59)
31.0(1.22)
34.0(1.34)
2.5(0.1) dia
www.martelmeters.com page 2 of 4
