Martel Electronics SP5-1200-BL - Manual (Page 2)

Panel thickness: 1.0 - 2.0
(0.04 - 0.08)
47.0 (1.85)
35.0
(1.38)
DIMENSIONS
All dimensions in mm (inches)
PANEL FITTING
CONNECTIONS
(rear view)
FUNCTIONAL BLOCK DIAGRAM
Vref
Module Seal Metal Clip
1
A/D +
_
V+
0V
BL+
BL-
a. 0.95 (0.04)
b. 6.5
(0.26)
c. 8.5 (0.33)
0V
V+
Page 2 of 3 www.lascarelectronics.com
SP 5-1200-BL
2-Wire Signal-Powered Meter
V+ 0V BL+ BL
-
a b c
34.0
(1.34)
36.0
(1.42)
46.0 (1.81)
48.0 (1.89)
14.4 (0.57) 14.4 (0.57)
Panel
2 3
Specifications liable to change without prior warning SP 5-1200-BL Issue 4 November/2003 M.C. Applies to SP 5-1200/2
PO Box 770, Londonderry, NH 03053 1-800-821-0023
www.martelcorp.com
