itting
the
B
owden
caBLe
(rcL²)
[
E–F
]
Danger of accident due to faulty installation work.
Î
–
Make sure that the Bowden cable on the RCL² can never interfere with
steering.
О
О
The outer sleeve must be laid via the shortest route, without torsion or
kinking, between the stops on the RCL² and the rear shock
(
10
)
.
)
Shorten the outer sleeve of the Bowden cable with suitable Bowden
cable pliers.
)
Make sure that the lever on the RCL² is relieved – press the return dial
if necessary.
)
Feed the inner cable through the RCL², outer sleeve and stop on the
rear shock.
)
Make sure that the outer sleeve is firmly seated in the stops.
)
Tension the inner cable, insert it into the groove on the rotating dial and
through the hole, and hold in place.
)
Tighten the clamping screw
(
11
)
with a tightening torque of
max. 2 N·m
(18 lbf·in).
)
Trim the inner cable to a length of approx 1 cm after the clamp screw
and fit a cable end cap.
)
Retension the inner cable after the first 10–20 actuations.
