Welcome to the PASSION PEOPLE!
You would like to equip your full-suspension bicycle with the variably
adjustable MAGURA TS rear shock.
Please read these instructions carefully before you use your MAGURA
product. Read and follow all the instructions in the manual provided by the
manufacturer of your bike frame.
The following instructions describe the basic fitting procedure of your
MAGURA TS rear shock. The detailed instructions in the operating manual
provided by the manufacturer of your bike frame should be followed.
You can find instructions for setup and maintenance of your rear shock in
the user instructions provided MAGURA
TS RL · TS RC.
Remember that the mechanic who installs your MAGURA product is
responsible for the suitability and compatibility of all the components
technically linked to your MAGURA product.
Never overestimate your technical capabilities. Commission a specialist
workshop for bicycles or an authorized MAGURA service centre with all
installation and maintenance work. This is the only way to ensure that
work is conducted in a professional manner.
Failure to observe the instructions in these user instructions can lead to
serious or fatal accidents.
Keep these mounting instructions for other users of your MAGURA product.
Visit
www.magura.com for more tips and information on your MAGURA
product. You can also exchange experiences, ask questions and generally
“talk shop” with many PASSION PEOPLE members on the MAGURA
Forum.
We wish you great success and a great ride
Your MAGURA Team
L
egend
) The pointing finger prompts you to perform an action.
О О The arrow shows results or requirements.
L L This notice gives you additional information or tips.
 This symbol refers to the corresponding chapter of the user instructions of
your rear shock.
This notice warns you about a dangerous situation which can lead to
serious or fatal injury if not avoided.
This notice warns you about the risk of material damage.
c
hecking diMensions [ A–B ]
) Make sure that the length L and stroke H of your rear shock meet the
requirements of the manufacturer of your bike frame.
) Make sure that the length A (bolt) and width B (spacer sleeves)
correspond to the dimensions C (stop points) of your bike frame.
) Make sure that the diameters D (mounting screws) correspond to the
internal diameter of the bolts.
L L Exclusively use genuine MAGURA bolts and spacer sleeves.
If necessary, contact your dealer or MAGURA directly to ask about the
wide variety of adapter solutions (bolts and spacer sleeves up to 45 mm
dimension, reduction sleeves for M6 mounting screws), if the supplied
components do not correspond to the dimensions of the stop points on
your bike frame or its mounting screws. In order to make the order
correctly, you will need to know dimensions
C of both the stop points
on your bike frame as well as the diameter dimensions D of the mount-
ing screws.
