̶ 5 ̶
3. SPECIFICATIONS
● AC current ranges
at 23±10℃ , 85% relative humidity
Ranges
Accuracy
Frequency Selector Switch
WIDE (40Hz-1kHz) position 50/60 Hz position
200mA 0-199.9mA ±1.0% rdg±4 dgt (50/60 Hz)
±1 .5% rdg±6 dgt
2000mA 0-1999mA ±3.0% rdg±4 dgt (40Hz-1kHz)
20A 0-19.99A ±1.5% rdg±4 dgt (50/60 Hz)
±2.0% rdg±6 dgt
200A 0-199.9A ±3.5% rdg±4 dgt (40 Hz-1kHz)
500A 0-500A
±2.0% rdg±4 dgt (50/60 Hz)
±2.5% rdg±6 dgt
±4.0% rdg±4 dgt (40Hz-1kHz)
Operating System: Dual Integration
Sensing: True RMS sensing
Digital Display: 3-1/2 digit liquid crystal display with
maximum reading of 1999
Overrange Indication: Numeral "1" on the highest digit flashes
Response Time: Approx. 2 second
Sample Rate: Approx. three times per second
Data Hold: For all ranges. In Data Hold mode, "H"
symbol is displayed on the digital display
Low Battery Indicator: "B" symbol is displayed on the digital
display.
Storage Temperature
and Humidity: -10℃~50℃ a t 75% m a x , r e l a t i v e
humidity without condensing
Operating Temperature: 0~40℃
Power Source: one 6F22 (DC9 V) battery or equivalent
Current Consumption: Approx. 4 mA
