Power Source
9V DC : R6P (SUM-3) x6
Overload Protection
Earth resistance ranges : 280V AC/DC (10 seconds)
Earth voltage range : 300V AC/DC (1 minute)
Insulation Resistance
5M Ω or more at 500V between the electrical circuit and the housing case
Withstand Voltage
3700V AC for one minute between the electrical circuit and the housing
case
Dimensions
105(L) x 158(W) x 70(D) mm
Weight
Approx. 550g
Accessories
M-7095 Test Leads x 1 set
M-8032 Auxiliary Earth Spikes x 2
M-7127 Simplified Measurement Probe x 1 set
(with safety alligator clip and flat test bar)
M-9084 Carrying Case x 1
Strap Belt x 1
Instruction Manual x 1
Battery R6P (SUM-3) x 6
---- 7 ----
Maximum Operating Error
Operating error (B) is an error obtained within the rated operating
conditions, and calculated with the intrinsic error (A), which is an error of
the instrument used, and the error (Ei) due to variations.
A : Intrinsic error
E
1
: Variation due to changing the position
E
2
: Variation due to changing the supply voltage
E
3
: Variation due to changing the temperature
E
4
: Variation due to series interference voltage
E
5
: Variation due to resistance of the probes and auxiliary earth
electrode resistance
E
7
: Variation due to changing the system frequency
E
8
: Variation due to changing the system voltage
Range to keep the maximum operating error
Measurement range within which the maximum operating error ( 30%)
applies.
20 Ω range : 5-19.99 Ω
200 Ω range : 20-199.9 Ω
2000 Ω range : 200-1999 Ω
Number of Measurement
3300 times or more
( Measure 10 Ω for 5s on 20 Ω range and take a pause for 25s)
Operating Temperature and Humidity
0 - 40°C, relative humidity 85% or less (no condensation)
Storage Temperature and Humidity
-20 - 60°C, relative humidity 75% or less (no condensation)
