OPERATION
4
33
OPTISENS PH 9100
www.krohne.com 09/2012 - 4002314801 - MA OPTISENS PH 9100 R02 en
Step 3a: accessing the calibration menu via the main menu setup
• You can start the calibration procedure now as described in "Step 4".
Step 3b: accessing the calibration menu via the main menu quick setup
• You can start the calibration procedure now as described in "Step 4".
• Press > for more than 2.5 seconds, then release the button. You are on the main menu level. In the
upper line of the display "A" appears, beneath the main menu quick setup is highlighted.
• Press or until the main menu setup is highlighted.
MAIN MENU
A quick setup
B test
> C setup
D service
• Press > to enter the chosen menu.
You are on the first submenu level. In the upper line of the display "setup" and "c1"
appears, beneath the submenu process input A is highlighted.
• Press or to select process input A or process input B is highlighted.
Choose process input A or B where ever pH is configured.
• Press > to enter the chosen menu.
You are on the second submenu level. In the upper line of the
display "process input A" and "C1.1" appears, beneath the
submenu parameter is highlighted.
• Press or until the submenu pH cal. is highlighted.
• Press > to enter the chosen menu.
• Press > for more than 2.5 seconds, then release the button. You are on the main menu level. In the
upper line of the display "A" appears, beneath the main menu quick setup is highlighted.
MAIN MENU
> A quick setup
B test
C setup
D service
• Press > to enter the chosen menu.
You are on the first submenu level. In the upper line of the display "quick
setup" and "a" appears, beneath the submenu language is highlighted.
• Press or until the submenu pH cal. A or B is highlighted, wherever pH
is configurated
• Press > to enter the chosen menu.
