cates. If OPTISWITCH with oscillator SW E60Z EX, SW E60Z

EX E1 should be operated directly on the analogue input of a

PLC, a suitable safety barrier should be connected.

4

3

2

1

1 2

+

-

Fig. 12: Wiring plan, single chamber housing

OPTISWITCH 5200 C, 5250 C - with two-wire output

19

Connecting to voltage supply

30435

-EN
