1 2 1 4
10... 55V DC 10... 55V DC
R
L
R
L
1
4
2
3
1
4
2
3
-
Max. Min.
- + +
Fig. 11: Wiring plan (housing) - Transistor output with M12x1 plug connection
1 Brown
2 White
3 Blue
4 Black
RL Load resistor (contactor, relay etc.)
OPTISWITCH 4000 C - with transistor output 17
Connecting to voltage supply
