7.2 Dimensions

Lock ﬁtting ARV 67 for OPTISWITCH 3300 C

~ 75mm (2

61

/

64

")

20mm

(

25

/

32

")

ø 43mm

(1

11

/

16

")

G2A/
2NPT

75mm

(2

61

/

64

")

Fig. 2: Lock ﬁtting ARV 67 up to 16 bar (232 psi) for OPTISWITCH 3300 C

Lock ﬁtting ARV 67 - up to 16 bar for OPTISWITCH 3300 C
