10 Screw the housing cover back on
The electrical connection is hence finished.
Fig. 7: Connection steps 5 and 6
5.3 Wiring plan, single chamber housing
4
1
2
3
Fig. 8: Electronics and connection compartment
1 DIL switch for mode adjustment
2 Ground terminal
3 Screwed terminals
4 Control lamp
Electronics and connection
compartment
