KROHNE OPTIFLEX 1300C ATEX EN - Manual (Page 11)

INSTALLATION
2
11
OPTIFLEX 1300 C
www.krohne.com 06/2010 - 4000091403 - AD ATEX OPTIFLEX 1300 R05 en
Equipment category 2 G, 2/3 G or 3 G:
Ex ia and Ex d[ia] devices - with the 4...20 mA output option
Temperature
class
Ambient temperature Flange temperature
Ø2 mm / Ø0.08¨ single
cable probe (HT
version)
Ø2 mm / Ø0.08¨ single
cable probe (other
versions)
All other probe types
[°C] [°F] [°C] [°F] [°C] [°F] [°C] [°F]
T6 -40…+57 -40…+134 -40…+57 -40…+134 -40…+57 -40…+134 -50…+60
1
-58…+140
1
-40…+53 -40…+127 -40…+49 -40…+120 -40…+52 -40…+125 -50…+85
1
-58…+185
1
T5 -40…+72 -40…+161 -40…+72 -40…+161 -40…+72 -40…+161 -50…+75
1
-58…+167
1
-40…+68 -40…+154 -40…+64 -40…+147 -40…+67 -40…+152 -50…+100
1
-58…+212
1
T4 -40…+80 -40…+176 -40…+80 -40…+176 -40…+80 -40…+176 -50…+85
1
-58…+185
1
-40…+75 -40…+167 -40…+72 -40…+161 -40…+75 -40…+167 -50…+110
1
-58…+230
1
-40…+72 -40…+161 -40…+65 -40…+149 -40…+70 -40…+158 -50…+135
1
-58…+275
1
T3 -40…+70 -40…+158 -40…+60 -40…+140 -40…+65 -40…+149 -50…+150
1
-58…+302
1
-40…+66
2
-40…+160
2
- - -40…+60
2
-40…+140
2
-50…+180
1
-58…+356
1
-40…+64
2
-40…+151
2
- - -40…+55
2
-40…+131
2
-50…+200
1
-58…+392
1
T2 -40…+57
2
-40…+134
2
- - - - -50…+250
1
-58…+482
1
-40…+50
2
-40…+122
2
- - - - -50...+300
1
-58…+572
1
1 Min. -50°C / -58°F, if an EPDM gasket is used. Min. -40°C / -40°F, if an FKM/FPM gasket is used. Min. -20°C / -4°F, if a Kalrez® 6375
gasket is used.
2 If the device has an adaptor for BM 100 probes, the flange temperature must be less than +150°C / +302°F
