1

INTRODUCTION

8

OPTIFLUX

www.krohne.com

04/2009 - 7.30685.22.00 - EX IFC 100 en

1.5 OPTIFLUX 5000

1.5.1 Field versions

OPTIFLUX 5000 F is certified as group II, category 2 GD equipment for gas hazardous areas zone
1 and 2, gas group IIC, temperature classes T6…T3 and dust hazardous areas zone 21 and 22,
surface temperature T85...180°C.
The sensor is available in "sandwich" and in "flange" version.

The connection box contains terminals for the connection of the field current and electrode
circuits:
Field current circuit

Field current circuit

Field current circuit

Field current circuit, in type of protection "Increased safety" (Ex e), terminals 7, 8 and 9:
U < 40 V (switched DC voltage, alternately +40 and -40 V), I = 125 mA (injected square wave
current),
Electrode circuit

Electrode circuit

Electrode circuit

Electrode circuit, in type of protection "Intrinsic safety" (Ex ia), terminals 1, 2, 3 and 4:
U

i

= 20 V , I

i

= 175 mA, C

i

≈ 0 nF, L

i

≈ 0 mH.

The before mentioned intrinsically safe circuits shall, from the safety point of view, be
considered to be connected to ground.
The cable gland for the electrode circuit is - as intrinsic safe circuit - marked with a blue O-ring.

The connection box contains terminals for the connection of the field current and electrode
circuits:
Field current terminals

Field current terminals

Field current terminals

Field current terminals, in type of protection "Increased safety" (Ex e), terminals 7, 8 and 9:
U < 40 V (switched DC voltage, alternately +40 and -40 V), I = 125 mA (injected square wave
current).
Electrode terminals

Electrode terminals

Electrode terminals

Electrode terminals, in type of protection "Intrinsic safety"(Ex ia), terminals 1, 2, 3 and 4:
U

i

= 20 V, I

i

= 175 mA, C

i

≈ 0 nF, L

i

≈ 0 mH.

The before mentioned intrinsically safe circuits shall, from the safety point of view, be
considered to be connected to ground.
The cable gland for the electrode circuit is - as intrinsic safe circuit - marked with a blue O-ring.

EEx marking OPTIFLUX 5000 F "sandwich":

EEx marking OPTIFLUX 5000 F "flange":

Nominal diameter

Nominal diameter

Nominal diameter

Nominal diameter

2.5...15

II 2 GD EEx me ia IIC T6...T3 T85...180°C

25...100

II 2 GD EEx de ia IIC T6...T3 T85...180°C

Nominal diameter

Nominal diameter

Nominal diameter

Nominal diameter

15...100

II 2 GD EEx e ia mb IIC T6...T3 T85...180°C
