TECHNICAL DATA
4
21
OPTIFLUX 2000
www.krohne.com 04/2014 - 4002298802 - QS OPTIFLUX 2000 R07 en
EN 1092-1
INFORMATION!
• All data given in the following tables are based on standard versions of the flow sensor only.
• Especially for smaller nominal sizes of the flow sensor, the signal converter can be bigger
than the flow sensor.
• Note that for other pressure ratings than mentioned, the dimensions may be different.
• For full information on signal converter dimensions see relevant documentation.
Nominal
size DN
[mm]
Dimensions [mm] Approx.
weight
[kg] Standard
length
ISO Insertion
length
H W
25 150 200 140 115 5
32 150 200 157 140 6
40 150 200 166 150 7
50 200 200 186 165 11
65 200 200 200 185 9
80 200 200 209 200 14
100 250 250 237 220 15
125 250 250 266 250 19
150 300 300 300 285 27
200 350 350 361 340 34
250 400 450 408 395 48
300 500 500 458 445 58
350 500 550 510 505 78
400 600 600 568 565 101
450 600 - 618 615 111
500 600 - 671 670 130
600 600 - 781 780 165
700 700 - 898 895 248
800 800 - 1012 1015 331
900 900 - 1114 1115 430
1000 1000 - 1225 1230 507
1200 1200 - 1417 1405 555
1400 1400 - 1619 1630 765
1600 1600 - 1819 1830 1035
1800 1800 - 2027 2045 1470
2000 2000 - 2259 2265 1860
