KROHNE OPTIFLUX 2000 Quickstart EN - Manual (Page 16)

2
INSTALLATION
16
OPTIFLUX 2000
www.krohne.com 04/2014 - 4002298802 - QS OPTIFLUX 2000 R07 en
2.10 Temperatures
CAUTION!
Protect the device from direct sunlight.
Temperature range Process [°C] Ambient [°C] Process [°F] Ambient [°F]
min. max. min. max. min. max. min. max.
Hard rubber / Polyolefin Hard rubber / Polyolefin Hard rubber / Polyolefin Hard rubber / Polyolefin 1
Separate flow sensor -5 80 -40 65 23 176 -40 149
Compact with IFC 300 -5 80 -40 65 23 176 -40 149
Compact with IFC 100 -5 80 -40 65 23 176 -40 149
Compact with IFC 050 -5 80 -40 65 23 176 -40 149
Polypropylene Polypropylene Polypropylene Polypropylene 2
Separate flow sensor -5 90 -40 65 23 194 -40 149
Compact with IFC 300 -5 90 -40 65 23 194 -40 149
Compact with IFC 100 -5 90 -40 65 23 194 -40 149
Compact with IFC 050 -5 90 -40 65 23 194 -40 149
1 Polyolefin is only available for DN200...1000
2 Polypropylene is only available for DN25...150
