INSTALLATION
14
OPTIFLUX 2000
www.krohne.com 04/2014 - 4002298802 - QS OPTIFLUX 2000 R07 en
Nominal size
DN [mm]
Pressure
rating
Bolts
Max. torque [Nm] 1
Polyolefin Polypropylene Hard rubber
25 PN 40 4 x M 12 - 22 11
32 PN 40 4 x M 16 - 37 19
40 PN 40 4 x M 16 - 43 25
50 PN 40 4 x M 16 - 55 31
65 PN 16 2 x M 16 - 51 42
65 PN 40 8 x M 16 - 38 21
80 PN 40 8 x M 16 - 47 25
100 PN 16 8 x M 16 - 39 30
125 PN 16 8 x M 16 - 53 40
150 PN 16 8 x M 20 - 68 47
200 PN 10 8 x M 20 68 - 68
200 PN 16 12 x M 20 45 - 45
250 PN 10 12 x M 20 65 - 65
250 PN 16 12 x M 24 78 - 78
300 PN 10 12 x M 20 76 - 76
300 PN 16 12 x M 24 105 - 105
350 PN 10 16 x M 20 75 - 75
400 PN 10 16 x M 24 104 - 104
450 PN 10 20 x M 24 93 - 93
500 PN 10 20 x M 24 107 - 107
600 PN 10 20 x M 27 138 - 138
700 PN 10 24 x M 27 163 - 163
800 PN 10 24 x M 30 219 - 219
900 PN 10 28 x M 30 205 - 205
1000 PN 10 28 x M 33 261 - 261
1 The specified torque values are dependent on variables (temperature, bolt material, gasket material,
lubricants, etc.) which are not within the control of the manufacturer. Therefore the values should be re-
garded as indicative only.
2 DN65 / PN16 is available with standard 8 bolt holes. On request 4 bolt holes is optional.
INFORMATION!
Other sizes / pressure ratings on request.
