20
DVD PLAYER
How to connect
1. Connect 3 separate components signal cables to the Y, Pb and Pr ports
of the component signal of the DVD player, and the Y, Pb and Pr ports of
the component signal of theTV set.
2. Connect the audio cable to the audio output port of the DVD player and
the audio input port of the component signal of the TV set.
How to use
1. Select COMPONENT.
2. Turn on the DVD set.
CAMERA CAMCORDER VIDEO GAME SET…
How to connect
1. Connect the camera, camcorder and game set to the ports of the
audio/video set.
2. The camcorder may get better picture by connecting a S-VHS cable
between the S terminal and the Audio set.
How to use it
1. Select the video AV or S terminal input.
2. Enable the exterior AV equipment.
Warning: In case you notice scrolling images, wrong colors or no color, no
picture or even combinations of these, on your screen, check if the
connections are done in the right way. Check if the cable colors match with
the Input connector colors.
