AOC L42H761 User Manual
AOC Televisions
L42H761
Description
42" Full HD LCD TV with Analog NTSC, Digital ATSC and Clear
QAM Tuners
Panel
Size
VIS: 42", Diagonal
Resolution
Widescreen 1920x1080, 16:9 Aspect Ratio
Pixel Pitch
0.1615(H)x0.4845(W)
Display Area
930.24mm x 523.26mm
Display Colors
16.7M
Brightness
500 cd/m2 (typ)
Contrast Ratio
1500:1 (typ)
Response Time
6.5ms Gray-Gray (typ)
Viewing Angle
Horizontal: 176 Degrees
Vertical: 176 Degrees
Analog TV Tuner
TV Tuning
NTSC
Color System
NTSC
Sound System
MTS + SAP
Closed Caption
Yes
V-Chip Parental Control
Yes
Digital Tuner
TV Tuning
ATSC (8VSB) with clear QAM
Video Inputs
Composite + L/R Audio
2
S-Video + L/R Audio
2
Component YCbCr/YPbPr
(480i/480p/720p/1080i) + L/R Audio
2
HDMI (High Definition Multimedia
Interface)
2
Graphic (PC) Input
Signal Input
Analog RGB (Dsub) and Digital HDMI1(DVI)
H-Frequency
31.5 ~ 75KHz
V-Frequency
56 ~ 62Hz
Recommended Resolution
1024x768 x60Hz
Plug & Play
DDC2B
Audio
Buit-in Speakers
20 Watts Total
Headphone Output
Yes
Digital Audio Output
S/PDIF (RCA Jack)
Power Source
Universal 100~240VAC, 50/60Hz (Internal)
Power Consumption
270W ( Max. )
User Control
Menu, Channel Up/Down, Power, Volume Up/Down, Mode
OSD Function
PC Mode
Picture Adjustment: Auto, Manual, Contrast, Brightness, Color
Temperature, Picture Format
TV Mode
Autoprogram, Weak Channel Installation, Menu language,
Closed Caption, Parental Control, Preferred Channels
TV & Video Mode
Auto Picture, Contrast, Brightness, Color,Sharpness, Color
Temperature, Tint, Picture Format, Dynamic Contrast.
Audio
Auto Sound, Sound mode, Alternate Audio, AVL, Digital language
Sleep Timer
Off, 180 minutes
Features
Video
De-interlacer, 3D Comb Filter, 3:2 Pull Down Recovery, Sleep
Timer
Audio
SAP, Mono, Stereo, Virtual Surround
Others
Wall Mountable**, Multi-function Remote, Multiple Picture Mode,
V-Chip Parental Control, Closed Caption,
Regulations
FCC, cULus
Included Accessories
Power Cord, RGB DB15 Cable, PC Audio Cable, Remote Control
w/ batteries, Base, User's Manual
Unit
41.3x30.2x11.4
Unit w/o Base
41.3x28.5x4.8
Carton
48.4x35.8x11.1
Weight (lbs)
Net
52.8
Gross
63.8
Loading Qty w/pallet
40' Std = 144 pcs., 20' = 64 pcs.
Warranty
1 Year
UPC Code
685417010882
Note: Specifications are subject to change without notice. *Wall Mount Arm & Bracket not included.
A0108
Dimensions (WxHxD inches)
