AVERAGE RMS VALUE – Page 9/9
AVGV
AVGI
AVGPatt
AVGPreat
=
=
=
=
0.0 V
0.0 A
0 W
0 Var
PAGE SCOPE HARM VECTORS
PARAMETERS CAPTION:
AVGV
 Average value voltage V1, V2, V3
AVGI  Average value current I1, I2, I3
AVGPact  Average value active power on L1, L2, L3
AVGPreact  Average value reactive power on
 L1,L2,L3
Fig. 27: Page of numerical average values
CAUTION
The AVERAGE RMS VALUES page will be shown only if option AVERAGE
VALUES “YES” is enabled in the Advanced Settings section (see § 5.3.2.5)
5.2.2. 3-wire three phase system – Screens sequence
12/09/2006 – 16:55:10
TOTAL RMS VALUES – Page x/y
V1PE
0.0
V2PE
0.0
V3PE
0.0 V
V12
0.0
V23
0.0
V31
0.0 V
NEG%
0.0
ZERO%
0.0
SEQ
000
Hz
0.0
I1
0.0
I2
0.0
I3
0.0 A
PAGE SCOPE HARM VECTORS
PARAMETERS CAPTION:
V1PE
 Phase L1-PE voltage
V2PE  Phase L2-PE voltage
V3PE  Phase L3-PE voltage
V12  Phase L1 – Phase L2 voltage
V23  Phase L2 – Phase L3 voltage
V23  Phase L3 – Phase L1 voltage
NEG%  Unbalance percentage of negative tern
ZERO%  Unbalance percentage of zero tern
SEQ  phases sequence indication as:
”123” = > Corrected
”132” = > Reversed
”023” = > Null voltage on the Black wire
”103” = > Null voltage on the Red wire
”120” = > Null voltage on the Brown wire
”100” = > Null voltage on the Red and Brown wires
”020” = > Null voltage on the Black and Brown wires
”003” = > Null voltage on the Black and Red wires
Hz
 Frequency
I1  Current on L1 phase
I2  Current on L2 phase
I3  Current on L3 phase
Fig. 28: Page of numerical values
12/09/2006 – 16:55:10
TOTAL POWER VALUES – Page x/y
Patt
Preatt
Papp
Pf
CosPhi
=
=
=
=
=
0 W
0 Var
0 VA
0.00i
0.00i
PAGE SCOPE HARM VECTORS
PARAMETERS CAPTION:
Pact
 Total Active Power
Preact  Total Reactive Power
Papp  Total Apparent Power
Pf  Total Power Factor
CosPhi  Total Power factor considering fundamental
 of voltage and current signals
Fig. 29: Page of total power values
