HT300
EN - 7
6. TECHNICAL SPECIFICATIONS
6.1. CHARACTERISTICS
Accuracy is indicated as [%rdg + degrees] at 23°C ± 5°C <80%RH
Temperature measurement with K probe
Range Resolution Accuracy Overload protection
-200 ~ 1370 °C 0.1 °C
±(0.05%rdg + 0.7 °C)
-328 ~ 2498 °F 0.1 °F
±(0.05%rdg + 1.4 °F)
24V DC
24V AC RMS
Temperature measurement with J probe
Range Resolution Accuracy Overload protection
-200 ~ 1050 °C 0.1 °C
±(0.05%rdg + 0.7 °C)
-328 ~ 1922 °F 0.1 °F
±(0.05%rdg + 1.4 °F)
24V DC
24V AC RMS
6.1.1. General data
Mechanical characteristics
Dimensions (LxWxH):
130 x 56 x 38 mm ; (5 x 2 x 1 in)
Weight (including battery): 170g (6 ounces)
Supply
Battery type:
1x9V alkaline NEDA 1604 IEC 6F22 JIS 006P
Low battery indication: “ ” symbol is displayed
Battery life: about 200 hours
Auto power off: after 15 minutes of idleness
Display
Characteristics:
double 5 LCD, sign and decimal point
6.2. ENVIRONMENTAL CONDITIONS
6.2.1. Climatic conditions
Reference temperature:
23°C ± 5°C ; (73°F ± 41°F)
Operating temperature: 5°C ÷ 40 °C ; (41°F ÷ 104°F)
Operating humidity: <80%RH
Storage temperature: -10°C ÷ 50°C ; (14°F ÷ 122°F)
Storage humidity: <70%RH
Max height of use: 2000m (6562 ft)
This instrument complies with the requirements of the EMC Directive 2004/108/CE
6.3. ACCESSORIES
Standard Accessories Optional accessories
¾
Instrument HT300
¾
TK107: type K probe for air and gas
¾
Type K bead probe
¾
TK108: type K probe for semisolid substances
¾
Carrying bag
¾
TK109: type K probe for liquid
¾
Battery
¾
TK110: type K probe for surfaces
¾
User manual
¾
TK111: type K probe for surfaces with 90° lead
