Detcon 971-041170-00L User Manual

Operator's instruction manual, Gas detection system

background image

Detcon Model 971-041170-00L

Gas Detection System

Operator's Instruction Manual

February 1, 1998 Document #1964 Rev 1.0

Detcon Model 971-041170-00L gas detection system consists of 2 major assemblies:

1. The NEMA 4 fiberglass sample draw enclosure.

2. The remote mount gas sensor assembly.

The NEMA 4 fiberglass sample draw enclosure is detailed in section 1 of this manual. The remote mount gas sensor

assembly is detailed in the attached sensor manual.
