SW-AV2-DV2
SW-AV2-DV2 Instruction Manual
Rev.0.3
Page 8 of 8
4.0 Parts List
Detcon Part #
Description
354-1916x6-024
24VDC Strobe, Ext Ground (x represents color of lamp)
Strobe colors: Red (2), Amber (4), Green (5), Blue (6), Magenta (7), and Clear (9)
356-DB3007-024
Model DB3 Horn
500-005146-000
24V Wireless Alarm Interconnect PCA
976-000300-316
Smart Wireless Transceiver
976-000320-316
Transparent wireless Transceiver
976-000303-012
12VDC. 2200mAh Battery Pack
976-0BP303-290
12VDC, 2900mAh Battery Pack
5.0 Specifications
Strobe
Dome Colors
Amber / Blue / Clear / Green / Magenta / Red
Flash Rate/Minute
60
Lamp Source
LED
Horn
Db Output
115db @ 1meter (tone dependent)
Duty Cycle
Not rated for continuous duty (5 minute duty cycle)
Alarm Unit
Operating Current
2.8A Max (both Horn and Strobe operational)
Operating Temperature
-20ºC to 60ºC
Voltage
12VDC
Dimensions
31.25”H X 17”W X 11.75”D
6.0 Warranty
Detcon Inc., as manufacturer, warrants under intended normal use each new SW-AV1-DV2, SW-A1-DV2, and
SW-V1-DV2 Alarm station to be free from defects in material and workmanship for a period of one year. The
warranty period begins from the date of shipment to the original purchaser and ends one year thereafter. All
warranties and service policies are FOB the Detcon Inc. facility located in The Woodlands, Texas.
7.0 Revision Log
Revision
Date
Changes made
Approval
0.0
04/25/11
Initial Release
LU
0.1
11/30/11
Updated Mounting Plate
LU
0.2
08/08/13
Update for new battery pack, new unit build, new PCA
LU
0.3
12/30/13
Corrections to Horn and other information
LU
Shipping Address: 4055 Technology Forest Dr. Suite 100, The Woodlands Texas 77381
Mailing Address: P.O. Box 8067, The Woodlands Texas 77387-8067
Phone: 888.367.4286, 281.367.4100 • Fax: 281.292.2860 •
•
