Detcon SW-AV1-DV1 User Manual
Page 10
SW-AV1-DV1
SW-AV1-DV1 Instruction Manual
Rev.1.1
Page 6 of 10
the cover on the junction Box, and ensure that the cover is completely screwed down and secured by the cap-
head screw.
Battery operation can be supplemented by the addition of an external 24VDC power source. The unit should
not need the addition of an external 24VDC power source, but if an external 24VDC is to be added, J6 is
provided for connection to the 24Volt input (refer to Figure 2). This voltage will be used to charge the battery
pack as well as aid in operation of the alarm station.
