Ask Proxima 64 User Manual
Page 9
USER GUIDE
LCD PANEL
8
5.1
COMPUTER
Connect the LCD panel, computer, monitor and power supply as shown in
the rear foldout.
Connect the VGA cable (1) between the LCD panel and the computer. Use
the Y-split on the computer end to connect the monitor.
If you have a Macintosh, EGA, CGA or NEC computer, insert applicable
adapters (4) and (5) as described in the table below.
Connect the power supply to the LCD panel (3).
APPLICABLE ADAPTERS :
COMPUTER
ADAPTER
VGA/SVGA
None
EGA/CGA*
EGA/CGA (option)
MACII c../v../LC/ Quadra/Powerbook/ Duo etc.
MACII (640 x 480)
(included)
NEC 9801
NEC 9801(option)
* Computer only, monitor not available
TO SET UP FROM THE BATMOUSE REMOTE CONTROL :
STEP
OPERATION
1
Press RESET for default settings
2
Adjust TUNE for a stable image
3
Press POSITION, then use cursor keys to position the image
4
Adjust CONTRAST as desired
