Model 12B
12B Control Module Instruction Manual Rev. 1.4 Page 11 of 12
10.4 Default Settings of Jumpers Tabs
Jumper Default Function
JP1 1 to 2 Alarm 3 (latched)
JP2 none Alarm 3 Firing Direction
JP3 none Configuration 4
JP4 none Configuration 5
JP5 1 to 2 Alarm 2 (latched)
JP6 none Alarm 2 Firing Direction
JP7 none Configuration 2
JP8 none Configuration 3
JP9 1 to 2 Alarm 1 (latched)
JP10 none Alarm 1 Firing Direction
JP11 none Configuration 1
JP12 1 to 2 Fault Alarm (latched)
JP13 1 to 2 Alarm 3 (de-energized)
JP14 1 to 2 Alarm 3 (normally open contacts)
JP15 1 to 2 Alarm 2 (de-energized)
JP16 1 to 2 Alarm 2 (normally open contacts)
JP17 1 to 2 Alarm 1 (de-energized)
JP18 1 to 2 Alarm 1 (normally open contacts)
JP19 2 to 3 Fault Alarm (energized)
JP20 2 to 3 Fault Alarm (normally open contacts when energized)
JP21 none Detector Load Bypass
11.0 WARRANTY AND SERVICE POLICY
Detcon, Inc., as manufacturer, warrants each new Model 12B series digital electronic control module to be free
from defects in material and workmanship under intended normal use for a period of one year from date of
shipment to the original purchaser. Detcon, Inc, additionally provides for a fixed fee repair/replace service
policy which covers Model 12B series digital control modules for a period of five years after expiration of the
warranty. The fixed policy rate is $75.00 per control module, per transaction, during the period of the policy.
The policy is FOB Detcon, Inc., The Woodlands, Texas.
