STEP 6
A. Lay Back Panel flat on a smooth surface with holes up.
B. Attach Side Panels with 1 3/4” machine screws (bolts) and hex nuts. After inserting bolts(s) thru the
holes in the Side Panels, thru the holes in the long edges of the Back Panel, place a hex nut on the
tip of your finger, align nut with bolt and tighten.
C. Look ahead to step 7 which shows side panels attached to back panel.
STEP 7
A. Invert cabinet assembly
from step 6.
B. Take the Top Front
Brace (with magnet
blocks), insert the pins in
the brace ends into the
slots on the inside of the
front legs of the Side Panel
and slide down until the
brace is aligned with the
set of holes in the Side
Panel as illustrated.
C. Secure brace with
1 3/4” machine screws and
hex nuts as in step 6.
